Corresponding instructions:

Applicable to high temperature and high pressure and strong corrosion conditions, the maximum working temperature is 760 degrees Celsius, and the highest working medium pressure is 240Mpa. Leakage rate can reach 1*10-10CM3/S

Specific content:

Assembly drawing

Due to the special cross-section of the metal V-ring, it has excellent high resilience performance and top sealing performance. We can provide products with round, rectangular and other complex shapes, which can be customized according to customer requirements.

Working conditions:

Working pressure range: vacuum --- 60MPA

Operating temperature range: -200 ° C - 760 ° C

Typical leak rate: 1*10-10CM3/S

Optional metal material:

 SUS321 stainless steel

SUS316L stainless steel

Inconel (718)

Inconel (750)

Optional plating:

silver (AG), tin (Sn), nickel (Ni), gold (Au), polytetrafluoroethylene (F4) and so on.

See the relevant groove size for details--"Website Download"
